Additional information
Weight | 6.2 kg |
---|---|
Technology | Lithium-ion (LiFePO4) |
Nominal Voltage | 12.8 Volt |
Nominal Capacity | 52 Ah |
Nominal Energy | 640Wh |
Resistance | ≤50 mΩ @ 50% SOC |
Charge Voltage | 14.2 V – 14.6 V |
Discharge Under-Voltage Protection | 9.3 V (2.325 ±0.08 vpc) (140 ±60 ms) |
Standard Charge Current | 2.5A – 25A |
Maximum Continuous Charge Current | 50A |
Maximum Continuous Discharge Current | 50A |
Peak Discharge Current | 100 A (7.5 s ±2.5 s) |
Bluetooth | No |
Length | 197 mm |
Width | 166 mm |
Height (inc. Terminals) | 173 mm |
Warranty | 3 Years |
Terminals | /wp-content/uploads/2017/03/RTerminal.jpg |
