Additional information
Weight | 3 kg |
---|---|
Technology | Lithium-ion (LiFePO4) |
Nominal Voltage | 12.8 Volt |
Nominal Capacity | 20 Ah |
Nominal Energy | 256Wh |
Resistance | ≤45 mΩ @ 50% SOC |
Charge Voltage | 14.2 V – 14.6 V |
Discharge Under-Voltage Protection | 8.0 V (2.0 ±0.08 vpc) (20 ±8 ms) |
Standard Charge Current | 1A – 10A |
Maximum Continuous Charge Current | 20A |
Maximum Continuous Discharge Current | 20A |
Peak Discharge Current | 40 A (7.5 s ±2.5 s) |
Bluetooth | No |
Length | 181 mm |
Width | 76 mm |
Height (inc. Terminals) | 169 mm |
Warranty | 3 Years |
Terminals | /wp-content/uploads/2017/03/RTerminal.jpg |
